EUROPE AND CIS
f
Material: Clay.
f
Bulk density: 1.5 t/m
3
.
f
Material size range: 500 mm inlet – <75 mm
outlet.
f
Flow rate – nominal: 300 tph.
Financiera y Minera, HeidelbergCement Group
Financiera y Minera, part of HeidelbergCement
Group, has awarded Bedeschi the supply of a
complete crushing station semi-mobile plant for
shale, with a capacity of 400 tph composed of:
f
1 apron feeder (below the receiving hopper).
f
1 crusher RL 850x2000.
f
2 transfer belt conveyors from crushing unit
to plant.
f
1 dedusting filter.
f
All structures and buildings to enclose the
crushing unit.
Summary:
f
Material: shale.
f
Bulk density: 1.5 t/m
3
.
f
Material size: 600 mm inlet – <100 mm outlet.
f
Design capacity: 500 tph.
Lloseta, CEMEX ESPAÑA
Fives has supplied a Pillard Fuelsystem Heavy oil
installation to the plant.
Oural Cement Plant, Votorantim Cimentos,
Cementos Cosmos
Dal Teknik Makina has conducted an audit to
analyse the alternative fuel burning efficiencies in
the calciner. Detailed measurements have been
taken from the calciner together with the preheater
cyclones, in order to simulate the existed inefficient
fuel feeding and gas flow conditions of the calciner.
With the measurement results and data taken
from the plant, several CFD analyses have been
developed for different fuel feeding points to figure
out the placement and angle for the most efficient
fuel burning.
Guided by the CFD analysis results and detailed
engineering of DTM, the alternative fuel burning
efficiency of Oural Cement Plant has been
increased.
Toral de los Vados Cement Plant, Votorantim
Cimentos – Cementos Cosmos
Dal Teknik Makina has conducted an audit to
figure out the bottlenecks of the pyroline together
with the raw mill unit, in order for the Toral de
los Vados Cement Plant to burn alternative fuels
without decreasing its production capacity.
After evaluating the current situation of the
plant, together with the measurement results and
documents given by the plant, Dal Teknik Makina
has prepared a detailed report pointing out the
needed improvements the plant has to carry out.
Tudela Veguin
Gorco was selected to carry out the substitution
of the existing old filter head at the Tudela plant
for nuisance applications.
The new filter includes the new cleaning system
injectors to adapt to the new technologies instead
of the old design.
Sweden
Oxelösund, Swecem AB
Gebr. Pfeiffer has been awarded a contract
for the supply and construction of a complete
granulated blast-furnace slag (GBFS) grinding
plant with a Gebr. Pfeiffer mill type MVR 2500
C-4. The plant is in Oxelösund, located on the
eastern coast of southern Sweden.
The new business partner is Swecem AB, part
of the Peab corporate group, one of northern
Europe’s leading construction companies.
Swecem AB operates in the field of cementitious
materials for concrete production and intends to
produce its own environmentally friendly cement.
The contract includes the supply and installation
from the top of the foundation up. It comprises
the complete process equipment, electrical
equipment and automation system as well as the
complete building on EPC basis.
The throughput of the Gebr. Pfeiffer mill type
MVR 2500 C-4 with its four equal-sized grinding
rollers and a table diameter of 2.5 m amounts
to 25 tph of slag powder (dry-base). The mill is
driven by an electric motor with 750 kW.
“Gebr. Pfeiffer’s core competences in grinding
technology and corresponding services are
constantly being improved and further developed.
In this instance, Gebr. Pfeiffer offers a service
agreement, starting from mechanical inspection
via process optimisation up to replacement of
main wear parts,” said Ludwig Zetterström, CEO
of Swecem AB.
Switzerland
LafargeHolcim Untervaz
Holcim Untervaz is one of the original plants of the
Holcim Group, which became the world leader in
cement with the Lafarge/Holcim merger.
Standard Industrie had already supplied
AIRCHOC air canons to this customer for their
preheating tower. This site required attention
concerning its productivity and therefore
contacted the company for the cleaning of a
1900 m
3
silo of cement of which 300 m
3
formed
rat holing.
Standard Industrie’s in-depth study aimed to
create the best conditions for the most efficient
intervention of its teams. Thus, in order to have a
wider cleaning perimeter with the GIRONET, two
